External Thread Turning Insert – ISO Full Profile 60°
The ISO Full Profile External Thread Turning Insert is designed for efficient and precise threading of metric threads in accordance with ISO standards. With a 5.0 mm pitch and a full-profile 60° form, this insert generates the entire thread profile—including crest, root, and flanks—in a single operation, making it ideal for high-load or coarse-thread applications.
Manufactured from premium P25C-grade carbide, the insert provides excellent wear resistance, cutting edge durability, and thermal performance. Its optimized X and Y geometry (1.7 mm and 2.5 mm) ensures smooth cutting, chip control, and thread accuracy during external right-hand operations.
Key Features:
- Ordering Code: 22 ER 5.0 ISO P25C
- Thread Type: ISO (Metric Thread Standard – 60°)
- Profile: 60° Full Form
- Insert Type: External
- Hand: Right Hand
- L: 22 mm
- I.C.: 1/2"
- Pitch: 5.0 mm
- X: 1.7 mm
- Y: 2.5 mm
- Carbide Grade: P25C
- Applications: External Thread Turning for ISO Metric Threads
- Key Advantage: Reliable full-profile threading for coarse pitches with superior tool life and dimensional control
Carmex Precision Tools Ltd. is a globally recognized leader in the development and manufacturing of high-quality cutting tools. With a strong focus on innovation and precision, Carmex offers a comprehensive range of solutions for threading, turning, and milling applications. From Thread Turning Inserts and Toolholders to Mill Thread systems and Solid Carbide threadmills, Carmex products are trusted by professionals worldwide for their reliability, accuracy, and exceptional performance across diverse industries and materials.
